环保配件/Environmental Protection Accessories
玻璃钢过滤储罐/FRP filter vessel
- mat:erial:FRP
- usage:water filter
- Product description: FRP filter vessel,玻璃钢过滤储罐 Adopt high-performance resin and glass fiber winding, Liner uses PE plastic, ABS, FRP high quality material to blow molding manufactory, using importing micro-computer contr
基本特点
主要制造工艺
原辅材料
产品规格
应 用
*优良的物理性能：玻璃钢的比重通常为1.8-2.1，是钢的1/4-1/5，比钢、铸铁、和塑料的比强度都高。玻璃钢的热膨胀系数与钢大体相当，热传导系数只有钢的0.5%。
*耐化学腐蚀，使用寿命长：玻璃钢具有特殊的耐腐性能，在储存腐蚀性介质时，玻璃钢显示出其它材料所无法比拟的优越性，可以耐多种酸、碱、盐和有机溶剂。
*设计灵活性大，罐壁结构性能优异：纤维缠绕玻璃钢可以改变树脂系统或增强材料来告诉玻璃钢贮罐及非标装置物理化学性能，以适应不同介质和工作条件的需要。通过结构层厚度、缠绕角和壁厚结构来设计调整罐体的承载能力，制成不同压力等级或某些特殊性能的玻璃罐及非标装置，这是各向同性的金属材料无法与其相比的。
由计算机控制，在芯模上按要求制作内衬层（例如防腐蚀内衬层），凝胶后按规定设计好的线型和厚度缠绕结构层，最后制作外保护层。
树脂、纤维毡、玻璃纤维缠绕纱等。
立式贮罐：直径1m-8m，容积1m3-600 m3
卧式贮罐：直径1m-4.2m，容积1m3-120 m3
运输槽车：直径1m-2.2m，容积1m3-60 m3
压力：常压-0.05MPa
-耐酸贮罐（盐酸罐、硫酸罐、磷酸罐、硝酸罐、有机酸罐、氟硅酸罐、氢氟酸罐等）
-耐碱贮罐
-盐水贮罐、污水贮罐
-玻璃钢/聚氯乙烯（FRP/PVC）、玻璃钢/聚丙烯（FRP/PP）复合罐
FRP water tank,FRP water softener tank,FRP filter vessel
1) Adopt high-performance resin and glass fiber winding, Liner uses PE plastic, ABS, FRP high quality material to blow molding manufactory, using importing micro-computer controlling equipment to shape, anticorrosion, high or low resistance ,high tenacity, satisfy customers' different applicatioin well.
2) merits: pretty twisting pattern , sophisticated manufacture, long lifetime, etc.
3) dimension: 7''-63”linner ABS/PE , above63″adopt FRP linner
4) opening: 2.5“whorl, 4“whorl mouth, 6″flange
Details
1) opening temperature: 1-49°C
2) operating pressure: 150PSI
3) bursting pressure: 232PSI
4) fatigue test: 100.000times incessantly cycle test
5) different inner container: FRP \ PE\ABS
6) opening diameter:2.5’’thread –6’’ flange
7) Certificates : CE ;NSF ; ISO9001 etc.
8) Warranty: 3 years
Color: Different colors are available, blue, grey, natural color, Apricot,Black ect.
Application: All feed water and waste water treatment application, included multi-media filter and softener.
|
specification |
volumel |
top opening |
bottom opening |
|
|
Inch |
mm |
L |
||
|
7×13 |
φ180×335 |
6.3 |
2.5”NPSM |
\ |
|
7×17 |
φ180×430 |
8.6 |
2.5”NPSM |
\ |
|
7×35 |
φ180×905 |
20.1 |
2.5”NPSM |
\ |
|
8×17 |
φ205×445 |
11.3 |
2.5”NPSM |
\ |
|
8×35 |
φ205×905 |
24.0 |
2.5”NPSM |
\ |
|
8×44 |
φ205×1130 |
32.5 |
2.5”NPSM |
\ |
|
9×35 |
φ230×905 |
32.0 |
2.5”NPSM |
\ |
|
9×42 |
φ230×1085 |
39.0 |
2.5”NPSM |
\ |
|
9×48 |
φ230×1230 |
44.7 |
2.5”NPSM |
\ |
|
10×17 |
φ255×445 |
17.8 |
2.5”NPSM |
\ |
|
10×35 |
φ255×905 |
38.6 |
2.5”NPSM |
\ |
|
10×44 |
φ255×1130 |
49.5 |
2.5”NPSM |
\ |
|
10×54 |
φ255×1390 |
61.9 |
2.5”NPSM |
\ |
|
12×52 |
φ300×1340 |
84.8 |
2.5”NPSM |
\ |
|
12×65 |
φ300×1650 |
106.3 |
2.5”NPSM |
\ |
|
13×54 |
φ330×1400 |
103.6 |
2.5”NPSM |
\ |
|
14×65 |
φ355×1670 |
145.6 |
2.5”NPSM |
\ |
|
14×65 |
φ355×1670 |
145.6 |
4”-8UN |
\ |
|
16×65 |
φ400×1670 |
187.7 |
2.5”NPSM |
\ |
|
16×65 |
φ400×1670 |
187.7 |
4”-8UN |
\ |
|
18×65 |
φ450×1670 |
237.0 |
4”-8UN |
\ |
|
21×69 |
φ530×1750 |
316 |
4”-8UN |
\ |
|
21×69 |
φ530×1750 |
316 |
4”-8UN |
4”-8UN |
|
24×72 |
φ600×1850 |
441 |
4”-8UN |
\ |
|
24×72 |
φ600×1850 |
421 |
4”-8UN |
4”-8UN |
|
24×87 |
φ600×2200 |
520 |
4”-8UN |
6”-8UN |
|
30×72 |
φ750×1850 |
676 |
6”-8UN |
\ |
|
30×72 |
φ750×1850 |
640 |
4”-8UN |
4”-8UN |
|
30×87 |
φ750×2200 |
790 |
4”-8UN |
6”-8UN |
|
36×72 |
φ900×1850 |
857 |
4”-8UN |
4”-8UN |
|
36×94 |
φ900×2400 |
1093 |
flange |
flange |
|
40×72 |
φ1000×1850 |
1046 |
4”-8UN |
4”-8UN |
|
40×94 |
φ1000×2400 |
1478 |
6”-8UN |
\ |
|
42×72 |
φ1070×1850 |
1100 |
4”-8UN |
4”-8UN |
|
42×94 |
φ1070×2400 |
1465 |
flange |
flange |
|
48×72 |
φ1200×1850 |
1202 |
flange |
flange |
|
48×94 |
φ1200×2400 |
1824 |
flange |
flange |
|
60×83 |
φ1500×2100 |
2158 |
